Stainless steel flat washer

Xiamen Hongyu Intelligent Technology Co., Ltd. has been deeply engaged in the field of precision metal stamping for over a decade. It possesses an independent production base and a complete quality control system, capable of providing a full range of specifications for Stainless steel flat washer and related hardware solutions. The company covers two main segments: standard parts supply on demand and non-standard parts customization development. From raw material selection, mold development to stamping and final product inspection, all processes are independently controllable. It supports various cooperation models and can fully meet the assembly and matching requirements for different scenarios.

Advanced stamping technology and practical application experience

We adopt a continuous mold high-speed stamping process for integrated forming, relying on CNC stamping equipment to achieve stable mass production, and produce Metal stamping Stainless steel flat washer. The workshop has multiple high-precision stamping machines, with tonnage ranging from 15T to 200T, and the maximum daily production capacity can reach 500,000 pieces, capable of efficiently handling large-volume orders.

Years of production practice have accumulated rich first-line manufacturing experience and a large number of on-site application cases in different working conditions. For outdoor high-humidity environments, weak acid corrosion environments, and continuous vibration equipment scenarios, the technical team can provide targeted product selection suggestions. For common assembly problems such as insufficient assembly clearance and pressure deformation, corresponding selection optimization solutions can be provided. Factory production real-shot materials and project application case materials can be provided to facilitate the partner's intuitive viewing of the product's performance in real projects.

Product performance parameters and professional selection capabilities

The stamping Stainless steel flat washer is made from 304 or 316 stainless steel substrates, which possess excellent anti-rust and anti-deformation capabilities. It can operate stably and for a long time within the temperature range of -20℃ to 200℃. The washer is processed using these materials. The inner diameter of the product ranges from M1.6 to M36, with a thickness of 0.2mm to 4mm. The conventional size tolerance is controlled within ±0.03mm, and the flatness error is less than 0.03mm. The assembly is tight.

Assembly protection function description

The core function of the Stainless steel flat washer is to expand the force-bearing area of the fastener, disperse the local pressure when tightening the bolt, avoid damaging the workpiece substrate by the fastener, and reduce the potential loosening hazard caused by long-term vibration. The product is manufactured strictly in accordance with international and domestic standards such as DIN125 and GB/T97.1. Salt spray tests, size sampling, and material spectral verification are conducted for each batch. The salt spray test for 304 material can last up to 48 hours without rust spots, and for 316 material, it can last up to 72 hours. The technical team can conduct product comparison analysis based on the equipment conditions and assist partners in selecting the appropriate washer specifications.

Non-standard customization development and industry authoritative qualifications

Customers only need to provide drawings or physical samples, and we can complete the mold evaluation, sample production, and batch production process to create Custom metal stamp Stainless steel flat washer. Customized widening, thickening, and special structure washers can be provided, and different surface treatment processes such as passivation and mirror polishing can also be offered, suitable for special narrow assembly spaces.

The company holds ISO9001 quality management system certification, the products meet RoHS environmental standards, and it can provide material proof and performance test reports issued by third-party authoritative institutions. Long-term stable cooperation with domestic and foreign mechanical manufacturing and new energy supporting brands has earned industry recognition for product quality.

The customization project is fully followed up, starting with sample performance verification and confirming the indicators before initiating large-scale production to avoid subsequent assembly risks.

The choice of material directly determines the overall assembly lifespan of the components. Different stainless steel materials have significant differences in the applicable working conditions. The selection of Stainless steel flat washer requires a comprehensive judgment based on the project's usage environment.

Applicable scenarios for different materials

The 304 stainless steel version is suitable for regular indoor and outdoor ordinary humid environments, with outstanding cost performance, and is the mainstream choice for general equipment assembly; the 316 stainless steel version contains molybdenum, which has stronger resistance to seawater and chemical corrosion, and is suitable for high-corrosion scenarios such as marine equipment and chemical equipment.

During the long-term operation of the equipment, high-quality stainless steel flat washers are less likely to rust or undergo creep deformation, and can continuously maintain the preload force of the connection structure, reducing the frequency of regular equipment maintenance. Our technical team can assist partners in selecting the most suitable material solution based on the environmental conditions and force parameters of the project. If samples are needed for project performance testing, please communicate with us via email.

FAQ

What Is a Stainless Steel Flat Washer Used For?

Stainless steel flat washer distributes bolt load evenly and protects mating surfaces against damage and corrosion during fastening.

What Is the Difference Between 304 and 316 Stainless Steel Washers?

304 stainless steel washers offer general corrosion resistance for ordinary environments, while 316 stainless steel washers contain molybdenum for superior anti-corrosion performance, suitable for marine and chemical scenarios.

What Sizes and Thicknesses Are Available?

We supply washers in multiple standard sizes and customizable thicknesses to match your bolt specifications and application requirements.
